The Cold Jet PCS Ultra in Medical Technology

The medical technology industry places the highest demands on cleanliness, precision, and sterility. Contamination or residues can impair the functionality of medical products and, in the worst-case scenario, endanger patient safety. This is where the Cold Jet PCS Ultra comes in, offering an efficient, safe, and environmentally friendly cleaning solution.

What is Dry Ice Blasting? 🌬️

Dry ice blasting involves propelling solid carbon dioxide particles (dry ice) at high speed onto the surface to be cleaned. Upon impact, the dry ice sublimates (changes directly from solid to gas), leaving no moisture or abrasive residues behind. This process loosens contaminants and coatings from the surface without damaging it.

Advantages of the Cold Jet PCS Ultra for Medical Technology ✨

• Gentle Cleaning: The PCS Ultra cleans surfaces non-abrasively. This is crucial for delicate medical instruments that have precise tolerances and must not suffer any damage or material removal.

• Residue-Free: Since dry ice sublimates, no secondary waste or residues are left behind. This eliminates the need for additional cleaning or drying steps, which is especially important for the sterility of medical devices.

• No Cross-Contamination: Unlike water- or chemical-based cleaning methods, there is no risk of cross-contamination from cleaning agent residues or water during dry ice blasting.

• Precision and Control: The PCS Ultra allows for fine adjustment of blast pressure and dry ice particle size. This enables highly precise cleaning of even complex geometries and hard-to-reach areas on medical devices and implants.

• Environmentally Friendly: Dry ice is made from recycled CO2 and is a sustainable cleaning solution that reduces the use of aggressive chemicals.

• Sterilization Preparation: The residue-free cleaning makes the PCS Ultra ideal for preparing medical products for sterilization processes, as it leaves a clean surface free of organic or inorganic contaminants that could impair sterilization.

Special Features of the Cold Jet PCS Ultra

The Cold Jet PCS Ultra is distinguished by a range of innovative features that further enhance its efficiency and user-friendliness in medical technology:

• Particle Control System (PCS®): This patented system allows for precise adjustment of particle size from 0.3 mm to 3 mm in tenths of a millimeter increments (28 sizes in total). This enables fine-tuning of blast parameters for each specific application, from gentle cleaning to more aggressive removal of contaminants.

• Intuitive Operation: A 7-inch color LCD screen with digital controls provides a clear display and easy adjustment of all blast parameters and machine settings.

• Programmable Application Recipes: Users can set and save blast pressure, particle size, and feed rate for recurring applications. This ensures consistency and reproducibility of cleaning processes.

• Defrost Cycle for Moisture Control: A patent-pending defrost cycle is integrated to control moisture, clean the core, and increase machine uptime, improving reliability in continuous operation.

• IoT Capability with Cold Jet CONNECT®: As an Industry 4.0 solution, Cold Jet CONNECT® offers remote monitoring and diagnostics, access to training videos and machine documentation, and self-guided troubleshooting. Direct contact with Cold Jet service technicians is also possible if needed.

• SureFlow Dosing System: The patented SureFlow system ensures consistent dry ice dosing, leading to consistent and efficient cleaning results.

• Optimized Design: The machine is made of stainless steel, compact, and features new motors for ultra-cold temperatures, as well as a core contamination control system to protect components. Redesigned blast hoses increase flexibility and durability.

• Low Noise Level: The PCS Ultra operates effectively at lower air and blast pressures, resulting in reduced noise levels and an improved working environment.

Further details about the Cold Jet PCS Ultra can be found on the Cold Jet website.

Application Areas in Medical Technology 🏥

The Cold Jet PCS Ultra finds diverse applications in medical technology, including:

• Cleaning of Molds for Medical Plastics: Removal of release agents and polymer residues from injection molds for medical components such as catheters or housings.

• Deburring and Surface Treatment of Implants: Gentle removal of burrs and improvement of the surface structure of prostheses or screws without affecting biocompatibility.

• Cleaning of Production Facilities: Cleaning of machines and equipment in cleanrooms and production lines to ensure compliance with strict hygiene regulations.

• Coating Removal: Precise removal of old coatings or residues before retreatment of medical instruments.

• Cleaning of Assemblies and PCBs: Gentle removal of flux residues or particles from electronic components in medical devices.

Conclusion 🎯

The Cold Jet PCS Ultra represents a groundbreaking technology for medical technology. Its ability to clean precisely, residue-free, and gently, combined with its innovative special features, significantly contributes to quality assurance and patient safety in a highly regulated environment. It is an investment that quickly pays off through improved product quality, reduced downtime, and optimized production processes.
